| 브랜드 이름: | Womeng |
| 모델 번호: | WM-SCK02 |
| 모크: | 1 조각 |
| 가격: | $500,000.00-$800,000.00 |
| 포장에 대한 세부 사항: | 항해 나무 상자 |
| 지불 조건: | l/c, d/a, d/p, t/t |
Product Info
|
Product size
|
M: 680X450 L: 800X650 XL: 950X760(Customixed according to customer requirement)
|
|
Product structure
|
Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
|
Control system
|
PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
|
|
Drive system
|
Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
|
|
Tension system
|
Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor. |
|
Safety system
|
It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
|
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
|
Materials corrective system
|
Materials corrective system: Adopt international famous brand deviation correction system |
|
Power
|
380V, 50HZ three phase five wire
|
|
Machine Capacity
|
400KW (Excluding glue machine and air compressor)
|
|
Bleed pressure
|
0.6-0.8Mpa (Air compressor needs to be prepared by customers)
|
Whatsapp: +008615805080212
https://www.diapersmachines.com
Stable and easy to operate: Reduce production failure and personnel training costs
Mature components ensure a low failure rate: Key components (such as the conveying system, cutting knife group, and glue bonding module) adopt mature designs commonly used in the industry, which have been verified by the long-term market and are less prone to failure. A single production line can operate stably for 16 to 22 hours a day (adjusted according to actual production capacity), reducing order delays caused by downtime.
Simple and easy to operate: Equipped with a multi-language (English, Spanish, Arabic, etc.) touch operation interface, core functions (such as start-up, speed regulation, and model change) are clearly marked, and a visual operation manual (including step diagrams) is also provided. Workers can operate independently after 1-2 weeks of training, without the need to hire professional technicians at high salaries, reducing labor costs.
Convenient and easy maintenance: The wear-prone parts (such as blades, conveyor belts, and sealing rings) are designed as "quick-release", and no complex tools are required for replacement. Local maintenance personnel of the customer can complete the task after a short period of training. At the same time, provide detailed maintenance guidelines (such as "which components to clean weekly and which parameters to check monthly") to avoid equipment wear and tear caused by improper maintenance.
Control the overall cost: It is more cost-effective from initial investment to long-term operation
The initial investment threshold is friendly: The overall design of the production line is compact. A workshop of about 1,200 square meters can complete the entire line layout (adjusted according to the actual area), reducing the customer's factory construction or rental costs. At the same time, a "basic version + on-demand upgrade" solution is provided (for example, the core production module is initially configured, and then the "automatic defect detection" module is added later), to avoid customers paying for functions that are temporarily not needed.
Low long-term operating costs: The energy consumption of the equipment during operation complies with international energy-saving standards, and long-term use can save electricity bills. In addition, the raw material utilization rate in the cutting and laminating processes is high (for example, "the loss rate of scraps is ≤4%"), reducing raw material waste, and is particularly suitable for regions with high raw material prices.
Localized services reduce after-sales costs: We have cooperative maintenance stations or reserve consumable parts in key markets such as Southeast Asia, South America, and Europe. Customers do not need to wait for cross-border logistics. When problems occur, they can enjoy "24-hour remote guidance + 48-72 hours on-site service" (adjusted according to the actual service area), reducing equipment idling time and minimizing production downtime losses.
화면
화면
화면
화면
화면
화면
화면
화면
|
